PoE-80 User’s Guide
22
PROBLEM CORRECTIVE ACTION
Power is not being
supplied to my PoE-
enabled devices. Ensure that the Ethernet cables connecting the PoE-enabled devices
to the PoE-80’s DATA OUT ports are securely attached. Make sure
the PoE-80 is connected to a power source.
7 Specifications
Standards IEEE 802.3af
Ports
8 DATA IN RJ-45 Ethernet ports
8 DATA OUT PoE injector RJ-45 Ethernet ports
1 RS-232 console port
LEDs
System: Power
Per Port (2 LEDs): Power Forwarding, Power Off
Power Output
-48V DC, 100 Watts maximum
Current (per port maximum): 350mA @ 48V DC
Management Microsoft Windows-based application for power management
Power Management
Functions
Current ports serviced list, system total serviced power budget, power
port disable/ enable, power support priority, power overload auto shut
down, power port operation status, power consumption limit
Weight 2.7 kg
Cooling 2 DC fans
Dimensions 440(W) x 224(D) x 44(H) mm (19” in width rack mountable)
Power Supply
100 - 240V AC, 50/60Hz internal universal power supply with fuse and
power switch
Power Consumption 130 Watts maximum
Operating Temperature 0 – 45 degrees Celsius (32 – 104 degrees Fahrenheit)
Operational Humidity 10% to 95% (Non-condensing)
EMI and Safety FCC Class A, CE, UL, cUL
