York STELLAR 2000 H*DA012 User Manual
Page 6
036-21105-004 Rev. A (0902)
6
Unitary Products Group
TYPICAL INSTALLATION
MATCHING INDOOR COMPONENTS
THERMOSTAT
TO
INDOOR
BLOWER
TO COIL
NEC
CLASS 2
WIRING
NEC
CLASS 1
WIRING
TO
POWER
SUPPLY
WEATHERPROOF
DISCONNECT
SWITCH
Seal opening(s) with permagum
or equivalent
24” SERVICE ACCESS
CLEARANCE
48” OVERHEAD
CLEARANCE
12” REAR AND
SIDES
NOTE: All outdoor wiring must be weatherproof
AIR HANDLERS - FOR NON-FURNACE APPLICATIONS
N1AH
MODULAR BLOWER
(UPFLOW, HORIZONTAL
AND DOWNFLOW)
F2RP
FAN COIL UNITS
(UPFLOW, HORIZONTAL)
G2FD
COIL
K*EU060,090
LIGHT COMMERCIAL
APPLICATIONS
G2FD*
MULTI-POSITION
(UPFLOW, HORIZONTAL
AND DOWNFLOW)
ADD-ON COILS - FOR FURNACE APPLICATIONS
