036-21187-001 REV A (0301)
Unitary Products Group 11
ELECTRICAL DATA
TABLE 17: OVERSIZE EVAPORATOR MOTORS - 2 TO 5 TONS
MODEL
DHH
VOLTAGE QTY
COMPRESSOR EVAPORATOR FAN CONDENSER FAN
MIN. CCT.
AMPACITY
MAX FUSE/
CCT. BKR. AMP
RLA LRA RLA LRA RLA LRA
024A06 208-230/1/60 1 @ 13.6 61.0 0.50 4.8 0.50 4.8 26.60 40
024A25 208-230/3/60 1 @ 8.6 55.0 0.50 2.4 0.50 2.4 15.55 20
036A06 208-230/1/60 1 @ 17.9 88.0 0.75 5.9 1.00 7.2 35.48 50
036A25 208-230/3/60 1 @ 11.4 77.0 0.75 3.1 1.00 3.7 21.05 30
036A46 460/3/60 1 @ 5.7 39.0 0.75 1.4 1.00 1.7 10.23 15
036A58 575/3/60 1 @ 4.7 31.0 0.75 1.1 1.00 1.5 8.48 15
048A06 208-230/1/60 1 @ 26.4 129.0 0.75 5.9 1.00 7.2 46.10 70
048A25 208-230/3/60 1 @ 15.0 99.0 0.75 3.1 1.00 3.7 25.55 40
048A46 460/3/60 1 @ 8.2 49.5 0.75 1.4 1.00 1.7 13.35 20
048A58 575/3/60 1 @ 6.4 40.0 0.75 1.1 1.00 1.5 10.60 15
060A25 208-230/3/60 1 @ 19.3 123.0 1.00 3.7 2.00 6.6 34.43 50
060A46 460/3/60 1 @ 10.0 62.0 1.00 1.7 2.00 3.0 17.20 25
060A58 575/3/60 1 @ 7.9 50.0 1.00 1.5 2.00 2.5 13.88 20
TABLE 18: OVERSIZE EVAPORATOR MOTORS - 8 TO 10 TON
MODEL DHH VOLTAGE QTY
COMPRESSOR EVAPORATOR FAN CONDENSER FAN MIN. CCT.
AMPACITY
MAX FUSE/
CCT. BKR. AMP RLA LRA HP FLA HP FLA
096A25 208-230/3/60 2 @ 15.0 99.0 2.00 6.6 3.00 9.2 49.55 60
096A46 460/3/60 2 @ 8.2 49.5 2.00 3.0 3.00 4.2 25.65 30
096A58 575/3/60 2 @ 6.4 40.0 2.00 2.5 3.00 3.6 20.50 25
120A25 208-230/3/60 2 @ 19.3 123.0 3.00* 9.2 5.00 14.3 66.93 80
120A46 460/3/60 2 @ 10.0 62.0 3.00* 4.2 5.00 6.6 33.30 40
120A58 575/3/60 2 @ 7.9 50.0 3.00* 3.6 5.00 5.7 27.08 30
144A25 208-230/3/60 2 @ 20.7 156.0 5.00 14.3 5.00 14.3 75.18 90
144A46 460/3/60 2 @ 10.0 70.0 5.00 6.6 5.00 6.6 35.70 45
144A58 575/3/60 2 @ 8.2 54.0 5.00 5.7 5.00 5.7 29.85 35
180A25 208-230/3/60 2 @ 32.1 195.0 5.00* 14.3 7.50 21.8 108.33 125
180A46 460/3/60 2 @ 16.4 95.0 5.00* 6.6 7.50 10.0 53.50 60
180A58 575/3/60 2 @ 12.0 80.0 5.00* 5.7 7.50 8.4 41.10 50
