ZyXEL Communications NWD-270N - Manual (Page 49)

NWD-270N User’s Guide
49
C
H A P T E R
5
Product Specifications
Table 15 Product Specifications
PHYSICAL AND ENVIRONMENTAL
Product Name NWD-270N Wireless N-lite USB Adapter
Interface USB 2.0
Standards IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (Draft 2.0)
Operating Frequency 2.4GHZ
Antenna Type Chip
Operating Temperature 0 - 50 degrees Celsius
Storage Temperature -30 - 70 degrees Celsius
Operating Humidity 20 - 90% (non-condensing)
Storage Humidity 10 - 90% (non-condensing)
Voltage 5V
Power Saving Mode Yes
Current Consumption Transmit: <300 mA
Receive: <160 mA
Weight 21g / 0.74oz
Dimensions 59 mm (L) x 24mm (W) x 13mm (H)
RADIO SPECIFICATIONS
Transmit Power 802.11b: Typical 18dBM
802.11g: Typical 15dBM
802.11n: Typical 15dBM
Receiver Sensitivity 802.11b: 11Mbps at -86dBm
802.11g: 54Mbps at -68dBm
802.11n: at -62dBm
WIRELESS STANDARDS
IEEE 802.11b Dynamically shifts between 11, 5.5, 2, and 1 Mbps network speed.
Operation Frequency 2.412GHz~2.472GHz
