Chapter 3 ZyXEL Utility - Mac OS X
NWD-270N User’s Guide
37
3.8 The Statistics Screen
This screen allows you to view statistics on network traffic between the NWD-270N and the
associated AP or peer computer. This screen is primarily for troubleshooting purposes.
Figure 16 ZyXEL Utility: Statistics
Channel This displays the wireless channel on which the network is operating.
Authentication This displays whether WPA, WPA2, WPA-PSK or WPA2-PSK is used on the
network. If the network uses no security or WEP, Unknown displays.
Encryption • When WPA, WPA2, WPA-PSK or WPA2-PSK is used, this displays the
encryption protocol used (TKIP or AES).
• When WEP is used, WEP displays.
• When no security is used, Not Used displays.
Network Type This field displays the network type (Infrastructure or Ad Hoc) of the wireless
device.
RESCAN Click this to update the list.
CONNECT Click this to connect to the highlighted wireless network.
ADD PROFILE Click this to go to the Add Profile: System Configuration screen.
Table 8 ZyXEL Utility: Site Survey (continued)
LABEL DESCRIPTION
