Fanfold Media
Fanfold media loads from the outside of the printer.
1. Thread the media through the access slot in the back of the printer
(refer to Figure 24 ).
2. Open the top cover.
3. Release the printhead by pulling the printhead release lever toward you
(refer to Figure 24, “1” ).
4. Lift the printhead (refer to Figure 24, “2” ) until you feel it “lock” into
place. Be careful not to force the printhead past this position!
5. Refer to Figure 25. Thread the media through the media guides.
NOTE: If the media guides must be changed to accommodate the
width of the media, turn the green media guide adjuster (refer to
Figure 25 ). The media guides should just touch, but not restrict,
the edges of the roll.
6. Continue to thread the media past the peel bar (refer to Figure 25 ).
7. Close the printhead by pressing down at both arrows (refer to
Figure 25 ).
8. Close the top cover and turn on the printer or press the feed button if
the printer is already on (see “Auto Calibration” on page 25 for more
information).
