Cutter Mode (optional)
1. Unlatch the top cover by pressing the two green release levers (refer to
Figure 18). Then, lift the top cover to expose the media compartment.
2. Insert one end of the media hanger into one of the media supply guides
3. Place the roll of media onto the media hanger.
4. Place the second media supply guide onto the other end of the media
NOTES: The media roll must be centered on the media hanger.
The media roll should rest against the smooth side of the media
supply guides. The textured side marked “out” should face the
outside of the printer. The media supply guides should just touch
the edges of the roll of media; they must not cause pressure or
excessive drag on the media roll.
5. Place the media roll in the top cover (refer to
6. Release the printhead by pulling the printhead release lever toward you
7. Lift the printhead (refer to
) until you feel it “lock” into
place. Be careful not to force the printhead past this position!
16
Release
Lever
Release
Lever
Figure 18
