Prestige 2602HW Series Quick Start Guide
10
Table 2 Front Panel LED Descriptions
LED COLOR STATUS
DESCRIPTION
On
Successful 10Mb Ethernet connection.
Green
Blinking
The Prestige is sending/receiving data.
On
The Prestige has a successful 100Mb
Ethernet connection.
Amber
Blinking
The Prestige is sending/receiving data.
LAN 1.. 4
Off
The LAN is not connected.
On
The Prestige is ready, but not sending/
receiving data through the wireless LAN.
Green
Blinking
The Prestige is sending/receiving data
through the wireless LAN.
WLAN
Off
The wireless LAN is not ready or has failed.
Fast Blinking
The Prestige is sending/receiving non-PPP
data.
Slow Blinking
The Prestige is initializing the DSL line.
Green
On
The DSL link is up.
On
The connection to the PPPoE server is up.
Amber
Blinking
The Prestige is sending/receiving PPP data.
DSL/ PPP
Off
The DSL link is down.
VoIP
Green
On
The VoIP SIP registration is OK.
Blinking
The Prestige is sending/receiving VoIP traffic.
Off
The VoIP SIP registration failed.
Green
On
The telephone(s) connected to this port is
(are) in use.
Phone 1-2
Blinking
The telephone(s) connected to this port is
(are) ringing.
Off
The telephone(s) connected to this port is
(are) not in use.
