261660-YTG-D-0708
12 Johnson Controls Unitary Products
TABLE 6: COOLING CAPACITIES FOR DJ240
Air on Evaporator Coil
Temperature of Air on Condenser Coil
85°F 95°F
CFM
WB
(°F)
Total
Cap. 1
(MBH)
Total
2
Input
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
Total
Cap.
1
(MBH)
Total
2
Input
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
6000
72 273.1 16.90 149.8 132.7 115.6 98.5 81.4 - - 257.3 18.45 150.2 133.1 116.0 98.9 81.8 - -
67 248.6 16.43 197.6 180.5 163.4 146.3 129.1 112.0 94.9 237.3 17.83 192.3 175.1 158.0 140.9 123.8 106.7 89.6
62 231.2 16.44 227.9 210.8 193.7 176.6 159.5 142.4 125.3 215.2 17.64 215.2 200.8 183.7 166.6 149.5 132.4 115.3
57 216.6 15.98 216.6 210.2 193.1 176.0 158.9 141.8 124.7 221.2 17.98 221.2 213.2 196.1 179.0 161.8 144.7 127.6
7000
72 278.7 16.96 165.8 145.6 125.4 105.1 84.9 - - 264.7 18.51 167.2 146.9 126.7 106.5 86.3 - -
67 253.8 16.49 217.5 197.3 177.1 156.9 136.7 116.5 96.2 244.2 17.89 213.1 192.9 172.7 152.4 132.2 112.0 91.8
62 236.0 16.50 234.4 225.8 210.0 189.8 169.6 149.4 129.2 221.5 17.70 221.5 214.3 200.7 180.5 160.3 140.0 119.8
57 221.1 16.04 221.1 217.9 209.3 189.1 168.9 148.7 128.5 227.6 18.04 227.6 223.6 214.2 194.0 173.8 153.5 133.3
8000
72 284.4 17.02 181.8 158.4 135.1 111.8 88.4 - - 272.2 18.58 184.1 160.8 137.4 114.1 90.8 - -
67 259.0 16.55 237.5 214.2 190.9 167.5 144.2 120.9 97.6 251.0 17.95 233.9 210.6 187.3 164.0 140.6 117.3 94.0
62 240.8 16.56 240.8 240.8 226.3 203.0 179.7 156.4 133.0 227.7 17.76 227.7 227.7 217.7 194.4 171.0 147.7 124.4
57 225.6 16.10 225.6 225.6 225.6 202.3 178.9 155.6 132.3 234.0 18.10 234.0 234.0 232.3 209.0 185.7 162.4 139.0
8700
72 291.0 17.43 193.1 167.5 141.8 116.1 90.4 - - 277.5 18.98 195.6 169.9 144.2 118.5 92.9 - -
67 265.0 16.95 251.7 226.0 200.3 174.7 149.0 123.3 97.6 256.0 18.33 247.4 222.2 196.5 170.8 145.2 119.5 93.8
62 246.4 16.96 246.4 246.4 237.6 211.9 186.2 160.5 134.9 232.2 18.14 232.2 232.2 227.2 201.5 175.8 150.1 124.5
57 230.8 16.49 230.8 230.8 230.8 205.2 179.5 153.8 128.1 238.6 18.50 238.6 238.6 237.7 212.1 186.4 160.7 135.0
9400
72 297.7 17.84 204.5 176.5 148.5 120.5 92.4 - - 282.9 19.38 207.0 179.0 151.0 123.0 94.9 - -
67 271.0 17.35 265.8 237.8 209.8 181.8 153.7 125.7 97.7 260.9 18.72 260.9 233.7 205.7 177.7 149.7 121.7 93.6
62 252.0 17.36 252.0 252.0 248.8 220.7 192.7 164.7 136.7 236.6 18.53 236.6 236.6 236.6 208.6 180.6 152.6 124.6
57 236.1 16.88 236.1 236.1 236.1 208.1 180.1 152.0 124.0 243.2 18.89 243.2 243.2 243.2 215.1 187.1 159.1 131.1
105°F 115°F
6000
72 244.1 20.09 146.5 129.4 112.3 95.2 78.1 - - 230.8 21.72 142.8 125.7 108.6 91.5 74.4 - -
67 225.3 19.63 186.7 169.6 152.5 135.4 118.3 101.2 84.1 213.4 21.43 181.2 164.1 147.0 129.9 112.8 95.7 78.6
62 202.7 19.37 202.7 194.9 177.7 160.6 143.5 126.4 109.3 190.2 21.09 190.2 188.9 171.8 154.7 137.6 120.5 103.4
57 211.7 19.63 211.7 205.7 188.6 171.5 154.4 137.3 120.2 202.2 21.28 202.2 198.2 181.1 164.0 146.9 129.8 112.7
7000
72 250.6 20.15 162.5 142.2 122.0 101.8 81.6 - - 236.4 21.79 157.8 137.5 117.3 97.1 76.9 - -
67 231.3 19.69 206.2 185.9 165.7 145.5 125.3 105.1 84.9 218.5 21.50 199.2 179.0 158.8 138.6 118.4 98.1 77.9
62 208.1 19.43 208.1 204.2 193.1 172.9 152.7 132.5 112.3 194.8 21.16 194.8 194.1 185.6 165.4 145.1 124.9 104.7
57 217.3 19.70 217.3 214.3 204.9 184.7 164.5 144.3 124.1 207.0 21.35 207.0 205.1 195.7 175.4 155.2 135.0 114.8
8000
72 257.0 20.22 178.4 155.1 131.7 108.4 85.1 - - 241.9 21.87 172.7 149.4 126.0 102.7 79.4 - -
67 237.3 19.76 225.6 202.3 178.9 155.6 132.3 109.0 85.6 223.6 21.58 217.3 193.9 170.6 147.3 123.9 100.6 77.3
62 213.5 19.50 213.5 213.5 208.5 185.2 161.9 138.5 115.2 199.4 21.24 199.4 199.4 199.4 176.0 152.7 129.4 106.1
57 222.9 19.77 222.9 222.9 221.3 197.9 174.6 151.3 128.0 211.9 21.43 211.9 211.9 210.2 186.9 163.5 140.2 116.9
8700
72 264.1 20.56 191.3 165.6 139.9 114.3 88.6 - - 250.6 22.15 187.0 161.3 135.6 110.0 84.3 - -
67 243.8 20.09 238.0 215.7 190.0 164.4 138.7 113.0 87.3 231.7 21.85 228.5 209.3 183.6 157.9 132.2 106.6 80.9
62 219.4 19.83 219.4 219.4 216.9 191.2 165.5 139.8 114.2 206.6 21.51 206.6 206.6 206.6 180.9 155.2 129.5 103.9
57 229.0 20.10 229.0 229.0 228.2 202.5 176.9 151.2 125.5 219.5 21.70 219.5 219.5 218.7 193.0 167.3 141.7 116.0
9400
72 271.1 20.91 204.1 176.1 148.1 120.1 92.1 - - 259.4 22.43 201.3 173.3 145.2 117.2 89.2 - -
67 250.3 20.43 250.3 229.2 201.1 173.1 145.1 117.1 89.1 239.7 22.13 239.7 224.6 196.6 168.6 140.5 112.5 84.5
62 225.2 20.16 225.2 225.2 225.2 197.2 169.2 141.1 113.1 213.8 21.78 213.8 213.8 213.8 185.7 157.7 129.7 101.7
57 235.2 20.43 235.2 235.2 235.2 207.1 179.1 151.1 123.1 227.2 21.98 227.2 227.2 227.2 199.2 171.1 143.1 115.1
125°F
6000
72 217.6 23.35 139.1 122.0 104.9 87.8 70.7 - -
67 201.4 23.23 175.7 158.6 141.5 124.4 107.3 90.2 73.1
62 177.7 22.82 177.7 177.7 165.8 148.7 131.6 114.5 97.4
57 192.7 22.93 192.7 190.8 173.7 156.5 139.4 122.3 105.2
7000
72 222.2 23.43 153.1 132.8 112.6 92.4 72.2 - -
67 205.6 23.31 192.3 172.1 151.9 131.7 111.4 91.2 71.0
62 181.5 22.90 181.5 181.5 178.0 157.8 137.6 117.4 97.1
57 196.8 23.01 196.8 195.8 186.4 166.2 146.0 125.7 105.5
8000
72 226.8 23.51 167.0 143.7 120.3 97.0 73.7 - -
67 209.9 23.39 208.9 185.6 162.3 138.9 115.6 92.3 68.9
62 185.2 22.98 185.2 185.2 185.2 166.9 143.5 120.2 96.9
57 200.8 23.09 200.8 200.8 199.1 175.8 152.5 129.1 105.8
8700
72 237.2 23.74 182.7 157.0 131.3 105.7 80.0 - -
67 219.5 23.61 219.0 202.8 177.1 151.5 125.8 100.1 74.4
62 193.7 23.19 193.7 193.7 193.7 170.6 144.9 119.2 93.6
57 210.0 23.30 210.0 210.0 209.2 183.5 157.8 132.1 106.5
9400
72 247.6 23.96 198.4 170.4 142.4 114.3 86.3 - -
67 229.1 23.84 229.1 220.0 192.0 164.0 136.0 107.9 79.9
62 202.3 23.41 202.3 202.3 202.3 174.3 146.3 118.2 90.2
57 219.2 23.52 219.2 219.2 219.2 191.2 163.2 135.1 107.1
1. The capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
