DNX024-048 Single Stage Gas Heat
Component
Models
DNX024 DNX036 DNX048
Nominal Tonnage 2.0 3.0 4.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu) 24.6 38.4 50.0
ARI net capacity (Btu) 24.0 37.0 48.0
EER 11.5 12.3 11.2
SEER 15.0 16.5 15.0
Nominal CFM 800 1275 1550
System power (KW) 2.1 3.0 4.3
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz) 7-8 9-12 9-8
ARI HEATING PERFORMANCE
Heating model 36 56 65 90 65 90 110
Heat input (K Btu) 45 70 80 108 80 108 135
Heat output (K Btu) 36 56 64 87 64 87 108
AFUE % 80.0 80.0 80.0 80.0 80.0 80.0 80.0
Steady state efficiency (%) 80 80 80 80 80 80 80
No. burners 2 3 3 4 3 4 5
No. stages 1 1 1 1 1 1 1
Temperature Rise Range (ºF) 25-55 30-60 25-55 45-75 25-55 35-65 45-75
Gas Limit Setting (ºF) 140 160 140 160 150 170 160
Gas piping connection (in.) 1/2 1/2 1/2
DIMENSIONS (inches)
Length 49 1/8 49 1/8 49 1/8
Width 47 1/4 47 1/4 47 1/4
Height 33 1/2 41 1/2 41 1/2
OPERATING WT. (lbs.) 440 480 500
COMPRESSORS
Type Scroll 2-spd Scroll 2-spd Scroll 2-spd
Quantity 1 1 1
CONDENSER COIL DATA
Face area (Sq. Ft.) 11.7 14.7 14.7
Rows 2 2 2
Fins per inch 20 20 20
Tube diameter (in.) 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 3.4 4.4 4.4
Rows 2 3 3
Fins per inch 15 16 16
Tube diameter 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV
CONDENSER FAN DATA
Quantity 1 1 1
Fan diameter (Inch) 22 22 22
Type Prop Prop Prop
Drive type Direct Direct Direct
No. speeds 1 2 1
Number of motors 1 1 2
Motor HP each 1/4 1/3 1/3
RPM 1100 900/1100 900/1100
Nominal total CFM 2400 2400 3000
DIRECT DRIVE EVAP FAN DATA
Quantity 1 1 1
Fan Size (Inch) 10 x 8 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal
Motor HP each 1/2 1 1
RPM Variable Variable Variable
Frame size 48 48 48
FILTERS
Quantity - Size 1 - 20 x 20 x 1 2 - 20 x 12 x 1 2 - 20 x 12 x 1
