Xantrex Technology Inc. PV-225208

Photovoltaic Inverter

Major Parts List

Assembly Description: Enclosure, DC Interface, PV-225208
Xantrex Technology Assembly # 151810

Item #

Qty

Reference Designator

Xantrex Technology Part #

Description

1

1

-

1-151783-01

Fab, Enclosure, DC Interface, PV225208

2

1

-

1-151755-01

Fab, Panel, Encl, DC, PV225208

3

1

S2

1-151669-04

Switch, Dscnct, Non-Fuse, 600V, 1200A

4

1

K2

1-151786-01

Contactor, 3P, 750A, 120VAC coil

5

1

TB5

1-151792-01

Block, Power Distribution, 1 Pole

151810

Sheet 2 of 2
