28
SPECIFICATIONS
AUDIO SECTION
Minimum RMS Output Power per Channel
Main L, R
8 ohms, 20 Hz to 20 kHz, 0.04% THD
......................................................50W+50W
Center
8 ohms, 1 kHz, 0.04% THD.....................50W
Rear
8 ohms, 1 kHz, 0.04% THD ....................20W
Maximum Power (EIAJ) [China and General
models only]
8 ohms, 1 kHz, 10% THD
Main L, R ....................................75W+75W
Center ..................................................75W
Rear ....................................................30W
Dynamic Power per Channel
(by IHF Dynamic Headroom measuring
method)
8/6/4/2 ohms
[U.S.A. and Canada models]
..........................................80/95/120/140W
[Europe, Australia, China and General
models] ...........................80/100/120/135W
DIN Standard Output Power per Channel
[Europe model only]
4 ohms, 1 kHz, 0.7% THD ...................75W
Dynamic Headroom (8 ohms)
[U.S.A. and Canada models only]
...........................................................2.04 dB
IEC Power [Europe model only]
8 ohms, 1 kHz, 0.1% THD ......................60W
Power Band Width
8 ohms, 25W, 0.1% THD
.............................................10 Hz to 50 kHz
Damping Factor
8 ohms, 20 Hz to 20 kHz ...............50 or more
Input Sensitivity/Impedance
PHONO MM......................2.5 mV/50 k-ohms
CD/TAPE·MD/VIDEO/VCR
.........................................150 mV/50 k-ohms
Maximum Input Signal
PHONO MM
1 kHz, 0.5% THD ............................100 mV
CD/TAPE·MD/VIDEO/VCR (EFFECT OFF)
1 kHz, 0.5% THD .................................2.5V
Output Level/Impedance
REC OUT........................150 mV/2.5 k-ohms
Headphones Jack Rated Output/Impedance
Output Level (8 ohms, 0.04% THD) .....0.45V
Impedance .....................................330 ohms
Frequency Response (20 Hz to 20 kHz)
CD/TAPE·MD/VIDEO/VCR ..............0±0.5 dB
RIAA Equalization Deviation
PHONO MM ....................................0±0.5 dB
Total Harmonic Distortion (20 Hz to 20 kHz)
PHONO MM to REC OUT
1V......................................................0.02%
CD/TAPE·MD/VIDEO/VCR to SP OUT
30W/8 ohms ......................................0.03%
Signal-to-Noise Ratio (IHF-A Network)
PHONO MM to REC OUT
(5 mV Input Shorted)..........................80 dB
CD/TAPE·MD/VIDEO/VCR to SP OUT
(Shorted) ............................................93 dB
Residual Noise (IHF-A Network)
MAIN L/R ............................................140
µ
V
Channel Separation (Vol. –30 dB, EFFECT
OFF)
PHONO MM
(Input Shorted, 1 kHz)........................60 dB
CD/TAPE·MD/VIDEO/VCR
(Input 5.1 k-ohms Terminated, 1 kHz)
...........................................................60 dB
Tone Control Characteristics
BASS: Boost/cut ...............±10 dB (50 Hz)
Turnover Frequency...........350 Hz
TREBLE: Boost/cut .............±10 dB (20 kHz)
Turnover Frequency..........3.5 kHz
Gain Tracking Error (0 to –60 dB) .............3 dB
VIDEO SECTION
Video Signal Level ..................1 Vp-p/75 ohms
Maximum Input Level ............1.5 Vp-p or more
Signal-to-Noise Ratio.................50 dB or more
Monitor Out Frequency Response
.....................................5 Hz to 10 MHz, –3 dB
FM SECTION
Tuning Range
[U.S.A. and Canada models]
..........................................87.5 to 107.9 MHz
[Europe, Australia, China and General
models]..............................87.5 to 108.0 MHz
50 dB Quieting Sensitivity (IHF, 75 ohms)
[U.S.A., Canada, Australia, China and
General models only]
Mono ...............................1.55
µ
V (15.1 dBf)
Stereo ................................21
µ
V (37.7 dBf)
Usable Sensitivity (75 ohms)
[Europe and Australia models only]
DIN, Mono (S/N 26 dB)......................0.9 µ V
DIN, Stereo (S/N 46 dB) .....................24 µ V
Image Response Ratio
[U.S.A., Canada, China and General models]
..............................................................45 dB
[Europe and Australia models] .............80 dB
IF Response Ratio
[U.S.A., Canada, China and General models]
..............................................................70 dB
[Europe and Australia models] .............80 dB
Spurious Response Ratio.........................70 dB
AM Suppression Ratio
[U.S.A., Canada, China and General models]
..............................................................55 dB
[Europe and Australia models] .............50 dB
Capture Ratio ..........................................1.5 dB
Alternate Channel Selectivity
[U.S.A., Canada, China and General models
only] .......................................................85 dB
Selectivity (two signals, 40 kHz Dev. ±300 kHz)
[Europe and Australia models only]
...............................................................70 dB
Signal-to-Noise Ratio
(IHF) Mono/Stereo
[U.S.A., Canada, China and General
models] .....................................80 dB/75 dB
(DIN-Weighted, 40 kHz Dev.) Mono/Stereo
[Europe and Australia models]
..................................................75 dB/70 dB
Harmonic Distortion (1 kHz)
[U.S.A., Canada, Australia, China and
General models]
Mono/Stereo ...................................0.1/0.2%
[Europe model]
Mono/Stereo (40 kHz Dev.) ............0.1/0.2%
Stereo Separation (1 kHz)
[U.S.A., Canada, Australia, China and
General models] ...................................50 dB
[Europe model (40 kHz Dev.)]..............50 dB
Frequency Response
20 Hz to 15 kHz..............................0 ±1.5 dB
