8
CONNECTIONS
Never plug in this unit and other components until all connections are completed.
CONNECTIONS WITH OTHER COMPONENTS
When making connections between this unit and other components, be sure all connections are made correctly, that is to say L (left)
to L, R (right) to R, “+” to “+” and “–” to “–”. Also, refer to the owner’s manual for each component to be connected to this unit.
* If you have YAMAHA components numbered as
1 , 3 , 4 , etc. on the rear panel, connections can be made easily by making sure
to connect the output (or input) terminals of each component to the same-numbered terminals of this unit.
*
1
,
*
2
: See page 10.
FM
ANT
AM
ANT
GND
75 Ω
UNBAL.
GND
MONITOR
OUT
VIDEO
VCR
IN OUT
VCR
PHONO VIDEO
PLAY REC IN OUT
1 3 4
VIDEO SIGNAL
TAPE/MD
AUDIO SIGNAL
I20V 60Hz
I00W MAX. TOTAL
SWITCHED
AC OUTLETS
CD
REAR
CENTER
MAIN
SINGLE:8 Ω MIN. /SPEAKER
DUAL:4 Ω MIN. /SPEAKER
8 Ω MIN. /SPEAKER
8 Ω MIN. /SPEAKER
REAR
CENTER
MAIN
SINGLE:6 Ω MIN. /SPEAKER
DUAL:3 Ω MIN. /SPEAKER
6 Ω MIN. /SPEAKER
4 Ω MIN. /SPEAKER
SET BEFORE POWER ON CENTER
MAIN
REAR
SINGLE
REAR
SPEAKERS
SEE INSTRUCTION MANUAL FOR CORRECT SETTING.
IMPEDANCE SELECTOR
GND
OUTPUT
VIDEO IN
AUDIO IN VIDEO IN
AUDIO OUT VIDEO OUT
LINE OUT LINE IN VIDEO OUT AUDIO OUT OUTPUT
(U.S.A. model)
To AC outlet
Turntable
LD player,
DVD player, etc.
Video cassette recorder
Tape deck,
MD recorder, etc.
CD player
Monitor TV
*
2
*
1
