York DNP036 - Manual (Page 15)

036-21366-007-A-1205
Unitary Products Group 15
TABLE 9: TWO TON AIR PERFORMANCE
1
MODEL #
DNP
(Cooling/
Heating)
MTR
SPD
EXTERNAL STAIC PRESSURE - IWG
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
CFM
W
A
TTS
SIDE SUPPLY AIR PERFORMANCE - 208 VOLT
024
HI - - - - - - - - - - 984 443 894 422 751 390 608 358 - - - -
MED 994 333 947 321 901 309 854 297 774 280 695 263 615 246 - - - - - - - -
LOW 743 243 700 235 657 226 614 218 - - - - - - - - - - - - - -
SIDE SUPPLY AIR BLOWER PERFORMANCE - 230 VOLT
024
HI - - - - - - - - - - - - 929 491 809 473 688 454 - - - -
MED - - - - 999 353 944 338 865 319 785 299 706 280 - - - - - - - -
LOW 998 372 906 333 813 294 721 255 651 241 - - - - - - - - - - - -
BOTTOM SUPPLY AIR BLOWER PERFORMANCE - 208 VOLT
024
HI - - - - - - - - - - 886 398 805 380 676 351 547 322 - - - -
MED 895 300 853 289 811 278 769 267 697 252 625 237 554 221 - - - - - - - -
LOW 669 219 630 211 591 204 553 196 - - - - - - - - - - - - - -
BOTTOM SUPPLY AIR BLOWER PERFORMANCE - 230 VOLTS
024
HI - - - - - - - - - - - - 836 442 728 425 620 409 - - - -
MED - - - - 899 318 850 304 778 287 707 269 635 252 - - - - - - - -
LOW 898 335 815 300 732 265 649 230 586 217 - - - - - - - - - - - -
1.
Above data includes allowances for a dry evaporator coil, gas heat exchanger and no filters. For additional pressure drops, refer
to Table 12 and 13.
