ZyXEL NWD-370N User’s Guide
Appendix A 57
A
P P E N D I X
A
Product Specifications
Table 21 Product Specifications
PHYSICAL AND ENVIRONMENTAL
Product Name NWD-370N Draft 802.11n Wireless PCI Adapter
Interface PCI bus 2.3
Standards IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft)
Network Architecture Infrastructure
Operating Temperature 0 ~ 50 degrees Centigrade
Storage Temperature -30 ~ 60 degrees Centigrade
Operating Humidity 20 ~ 95% (non-condensing)
Storage Humidity 20 ~ 95% (non-condensing)
Power TX power consumption: < 690 mA
RX power consumption: < 600 mA
Voltage 3.3 V
Weight 145 g
Dimension (L) 120 mm × (W) 97.5 mm × (H) 20 mm
RADIO SPECIFICATIONS
Media Access Protocol IEEE 802.11
Frequency Industrial Scientific Medical Band
2.4 ~ 2.4835 GHz (IEEE 802.11b/g)
Operating Channels North American and Taiwan: 11
Europe: 13
Data Rate IEEE 802.11b: 11Mbps with automatic fallback to 5.5, 2, 1 Mbps
IEEE 802.11g: 54Mbps with automatic fallback to 48, 36, 24, 18, 12,
9, 6 Mbps
IEEE 802.11n (draft): up to 300 Mbps
Modulation IEEE 802.11b: CCK (11 and 5.5 Mbps), DQPSK (2 Mbps) and
DBPSK (1 Mbps)
IEEE 802.11g: OFDM with BPSK, QPSK and 16/64-QAM sub-
Carrier modulations
Average Output Power Tolerance: +/- 1.5 dBm
IEEE 802.11b: 18 dBm at 11 Mbps
IEEE 802.11g: 15 dBm at 54 Mbps
IEEE 802.11n (draft): 14 dBm at HT20 & HT40
