ZyXEL NWD-370N User’s Guide
40 Chapter 4 Wireless Configuration
4.3.1.2 WPA-PSK/WPA2-PSK
Figure 23 Security Setting: WPA-PSK/WPA2-PSK
Key x (where x is a
number between 1
and 4)
Select this option if you want to manually enter the WEP keys. Enter the WEP key
in the field provided.
If you select 64 Bits in the WEP field.
Enter either 10 hexadecimal digits in the range of “A-F”, “a-f” and “0-9” (for
example, 11AA22BB33) for HEX key type.
or
Enter 5 ASCII characters (case sensitive) ranging from “a-z”, “A-Z” and “0-9”
(for example, MyKey) for ASCII key type.
If you select 128 Bits in the WEP field,
Enter either 26 hexadecimal digits in the range of “A-F”, “a-f” and “0-9” (for
example, 00112233445566778899AABBCC) for HEX key type
or
Enter 13 ASCII characters (case sensitive) ranging from “a-z”, “A-Z” and “0-9”
(for example, MyKey12345678) for ASCII key type.
If you select 152 Bits in the WEP field,
Enter either 32 hexadecimal digits in the range of "A-F", "a-f" and "0-9" (for
example, 00112233445566778899AABBCCDDEEFF) for HEX key type
or
Enter 16 ASCII characters (case sensitive) ranging from "a-z", "A-Z" and "0-9"
(for example, MyKey12345678901) for ASCII key type.
Note: The values for the WEP keys must be set up exactly the
same on all wireless devices in the same wireless LAN.
ASCII WEP keys are case sensitive.
Back Click Back to go to the Site Survey screen to select and connect to another
network.
Next Click Next to confirm your selections and advance to the Confirm Save screen.
Refer to Section 4.3.2 on page 43 .
Exit Click Exit to return to the Site Survey screen without saving.
Table 8 Security Setting: WEP (continued)
LABEL DESCRIPTION
