York D*V - Manual (Page 18)

DESCRIPTION:
PROJECT: TAG:
DATE:
Gross Cooling Capacity [Btuh]: 244,000*
Design CFM: 8,000
Energy Efficiency Ratio: 10.10 EER**
Net Cooling Capacity [Btuh]: 236,000**
Net Cooling CFM: 6,800
Refrigerant: R22
Charge: 18.35 Lbs./ circuit
Compressor No./Type: 2/Scroll
Refrigerant Circuits: 2 / Independent
Evaporator Coil Face Area: 19.00 [sq ft]
Rows/FPI : 4/10
Refrigerant Control: TX Valve
Filters - Qty./Size: 6/20x25x2
Condenser Coil Face Area: 20.55 [sq ft]
Rows/FPI: 4/14
Evaporator Fan No./Type: 2/CENTRIFUGAL
Diameter x Width [in]: 15x15
Drive: Adjustable Belt
Motor HP : 5.0 / 7.5
[Standard/Oversized]
Condenser Fan No./Type: 2/CENTRIFUGAL
Diameter x Width [in]: 18x13
Drive: tl e B e l b a t s u j d A
Motor HP : 7.5
[Standard]
Operating Weight [lbs.]: 1720
Shipping Weight [lbs.]: 1805
Condensate Connection: 3 / 4 NPT
*Cooling performance is rated at 95 ° F ambient, 80 ° F entering dry bulb, 67 ° F wet bulb
and CFM listed. Gross capacity does not include the effect of fan motor heat.
**Rated in accordance with ARI Standard 360-2000
NOTE:
1. At high evaporator air flows, and wet bulb conditions, condensate carry-over may occur. Adjust airflow downward as necessary.
2. Values include pressure drop from wet coil and clean filters.
3. Shaded areas indicate oversize motors.
EVAPORATOR FAN PERFORMANCE
CONDENSER FAN PERFORMANCE
ELECTRICAL DATA – STANDARD MOTOR
MODEL SUPPLY 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
# CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
7200
8000
DPV240
DPV240
DPV240
DPV240
DPV240
DPV240
DPV240
DPV240
10200
657 1.89 717 2.19 774 2.51 829 2.84 875 3.18 933 3.53 972 3.89 1024 4.26 1072 4.63 1113 5.02
717 2.51 772 2.84 825 3.20 875 3.55 924 3.92 976 4.31 1022 4.72 1062 5.15 1105 5.60 1145 6.07
8800 778 3.27 830 3.64 878 4.01 925 4.40 970 4.79 1015 5.20 1067 5.63 1102 6.08 1140 6.54 1183 7.03
EXTERNAL STATIC PRESSURE - Inches W.C.
EXTERNAL STATIC PRESSURE - Inches W.C.
MODEL OUTDOOR 0.2 0.4 0.6 0.8 1.0 1.2
# CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
656 3.72 700 4.12 741 4.50 781 4.91 820 5.32 857 5.73
MODEL VOLTAGE COMPRESSOR EVAPORATOR FAN CONDENSER FAN MIN. CCT. MAX FUSE /
# QTY RLA LRA HP FLA HP FLA AMPACITY CCT. BKR. AMP
208-230/3/60 2 @ 33.6 225.0 5.00 13.7 7.50 22.2 111.50 125
460/3/60 2 @ 17.3 114.0 5.00 6.6 7.50 10.8 56.33 70
575/3/60 2 @ 13.5 80.0 5.00 5.3 7.50 8.2 43.88 50
MODEL VOLTAGE COMPRESSOR EVAPORATOR FAN CONDENSER FAN MIN. CCT. MAX FUSE /
# QTY RLA LRA HP FLA HP FLA AMPACITY CCT. BKR. AMP
208-230/3/60 2 @ 33.6 225.0 7.50 22.2 7.50 22.2 120.00 150
460/3/60 2 @ 17.3 114.0 7.50 10.8 7.50 10.8 60.53 70
575/3/60 2 @ 13.5 80.0 7.50 8.4 7.50 8.4 47.18 60
ELECTRICAL DATA – OVERSIZED MOTOR
March 2008
DPV240 VERTICAL UNIT
SELF-CONTAINED AIR-COOLED
Form YK145.12-PA8 (308)
1 of 4
Johnson Controls maintains a continuous product improvement policy, therefore specifications are subject to change without notice.
Page 18
