P841C Central-Side VDSL Modem
4-2 VDSL-Related Commands
Table 4-3 VDSL Mode, Frequency Ranges and Rates
VDSL MODE FREQ. RANGE (Hz) RATE (Mbps)
10 Base-S
Upstream 4.0M 7.9M 1.56 6.25 9.38 12.50 18.75
Downstream 900K 3.0M 4.17 6.25 8.33 12.50 16.67
ANSI Mode (ANSI/ETSI Band Plan 998)
Upstream 4.0M 5.0M 1.56 3.13 6.25
Downstream 900K 3.0M 4.17 6.25 8.33 12.50 16.67
ETSI Mode (ETSI Band Plan 997)
Upstream 4.0M 5.0M 1.56 3.13 6.25
Downstream 900K 2.7M 4.17 6.25 9.38 12.50
4.1.2 VDSL Active Command
vdsl active [on|off]
Use this command to activate or deactivate the VDSL driver.
4.1.3 VDSL Uprate and Downrate Commands
Use the following commands to view and set VDSL upstream and downstream rates. Rates vary according to
VDSL mode selected – see Table 4-4 and section 4.1.1.
Upstream Rates
vdsl uprate [uprate]
“uprate” is an integer from 0 to 4 as defined in the next table. This command sets the upstream VDSL rate if you
set a rate and displays the rate if you don’t. If you set a new rate, you must use “vdsl reset” or “vdsl reconnect”
command to reconnect.
Figure 4-2 VDSL Upstream Rate
Downstream Rates
vdsl downrate [downrate]
“downrate” is an integer from 0 to 4 defined in the next table. This command sets the upstream VDSL rate if you
set a rate and displays the rate if you don’t. If you set the rate, you must use “vdsl reset” or “vdsl reconnect”
command to make VDSL reconnect.
P841C>vdsl uprate
vdsl upstream rate: 1562500 bps (0)
