Using the airplane power plug – Xantrex Technology Powerpack 100 User Manual
Page 21
16
Using the Airplane Power Plug
1.
Plug the DC input cable into the DC input port on
the inverter module. Observe correct polarity. See
Figure 4.
2.
Insert the airplane power plug into the 12 V
outlet.
3.
Plug the device you want to operate into the
inverter module. See “Inverter Operation” on
page 20.
CAUTION: Reverse polarity damage
When plugging in the DC cable, ensure that the plug
aligns with the DC cable port. Failure to do so will
result in reverse polarity and a blown fuse.
