28
AUTO SETUP
7
Press n to select START PUSH i , then press
h .
Loud test tones will be output from each speaker and
WAIT appears during the auto setup procedure.
If “E-10:OTHER ERROR” appears during testing, restart the
procedure from step 3.
If you selected “AUTO” in step 6
The RESULT display appears for a few seconds after each
check, then settings of the next item will start. The
RESULT:EXIT display appears after all items are set.
y
You can display each result by pressing k once and pressing h
repeatedly before exiting. Pressing n returns to the
RESULT:EXIT display.
8
To apply the changes, press l / h to select
SET, then press n to exit.
To cancel the auto setup procedure, press
l / h to select CANCEL, then press n to exit.
If you selected “STEP” in step 6
The RESULT display appears after each check.
8
Press l / h to display RESULT:EXIT, then
press l / h to select:
NEXT Then press n to proceed and check the next item.
EXIT Then press n to exit the auto setup.
y
• Press k / n repeatedly to move between each display.
• If you are not satisfied with the result or want to manually
adjust each setup parameter, use the manual setup parameters
(see page 55).
• If you change speakers, speaker positions, or the layout of your
listening environment, perform AUTO SETUP again to re-
calibrate your system.
• In the DISTANCE results, the distance displayed may be longer
than the actual distance depending on the characteristics of your
subwoofer.
• In the EQUALIZING results, different values may be set for the
same band to provide finer adjustments.
If you selected “RELOAD” in step 6
The RESULT:EXIT display appears.
y
You can display each result by pressing k once and pressing h
repeatedly before exiting. Pressing n returns to the
RESULT:EXIT display.
8
Press l / h to select “SET”, then press n to
exit.
Note
/ : Up/Down
p
p
: Back/Next
RESULT:WIRING
FRONT L;;;;;;;OK
/ : Up/Down
p
p
EQ;;;;;FRONT L
63Hz;;;-2.0dB
125Hz;;;-5.0dB
500Hz;;;;;;0dB
630Hz;;;;;;0dB
1.0kHz;;;;;;0dB
3.15kHz;;;+3.0dB
10.0kHz;;;+1.0dB
RESULT:EQUALIZI.
/ : Up/Down
p
p
: Back/Next
. FRONT L;;;;3.20m
CENTER;;;;;3.30m
FRONT R;;;;2.90m
PRES L;;;;;1.70m
PRES R;;;;;1.50m
RESULT:DISTANCE1
/ : Up/Down
p
p
: Back/Next
. FRONT L;;;+5.0dB
CENTER;;;;-4.5dB
FRONT R;;;+5.5dB
PRESENCE;;-3.0dB
RESULT:LEVEL 1
/ : Up/Down
p
p
: Back/Next
FRONT L;;;;;;LRG
RESULT:SIZE 1
Notes
