Appendix D: LED Description 45
Appendix D
LED Description
The following table describes each of the LEDs on the top of the
Game Point! and what each light means when it is flashing and/or
steady.
LED What it does Flashing/Steady Status
TX/RX Shows the
status of the
Game Point!’s
wireless link When flashing green, the Game
Point! is sending or receiving data
wirelessly.
LINK/ACT Shows the
status of the
Game Point!’s
Ethernet LAN
connection
•
If it flashes green and then
becomes steady green, the Game
Point! has established a valid 100
Mbps Ethernet connection.
•
If it flashes orange and then
becomes steady orange, the
Game Point! has established a
valid 10 Mbps Ethernet
connection.
•
When flashing (regardless of
color), the Game Point! is sending
or receiving data over the
Ethernet LAN.
PWR Shows whether
the Game Point!
is powered on. When steady green, the Game
Point! is powered on.
