CONTROL PANEL – W/CHARGER
86221970 17” SCRUBBER 01/03/07
5-4
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86007130 72128 1 SWITCH, DPDT 2-POSITION ROCKER
2 86007140 72130 1 SWITCH, SPST 2-POSITION ROCKER
3 86257090 72181 1 SWITCH, DPST 2-POSITION ROCKER
4 86276820 70740 6 SCR, 10-32 X 1/2 PTHMS BLK NP
5 86218800 41540 1 HANGER, CHARGER CORD 172
6 86215420 140888 2 BOOT, M12 CIRCUIT BREAKER
7 86215860 140913 1 BRKT, HOSE HOOK
8 86231240 140429 1 BUSHING, .75 ID X .25 H
9 86255910 73659 2 STANDOFF, 1/4-20 X 1.0 HEX INS
10 86006850 70393 2 SET SCR, 1/4-20 X 1.25 L
11 86222310 57311 3 NUT, 1/4-20 UNC
12 86005640 57030 4 NUT, 10-32 HEX NYLOCK
13 86215680 140931 2 BREAKER, 25A, 250VAC 50VDC
14 86005680 57047 2 NUT, 1/4-20 HEX NYLOCK
15 86274290 70162 2 SCR, 10-32 X 3/8 PPHMS SS
16 86222490 61480 1 PANEL, SCRUBBER 17 IN
17 86010660 87025 5 WASHER, 1/4 LOCK EXT STAR SS
18 86224880 730365 4 STANDOFF, HEX BRASS 6-32 THRD
19 86246970 54192 1 METER, 24V BATTERY W/OUTPUT
20 86251420 67610 1 RELAY, 24VDC 40A /BRKT
21 86218070 35358 2 GASKET, ELECTRIC COVER SIDE
22 86218080 35359 1 GASKET, ELECTRICAL COVER
