SQUEEGEE LIFT
86221970 17” SCRUBBER 01/03/07
5-26
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86005680 57047 1 NUT, 1/4-20 HEX NYLOCK
2 86270830 57023 2 NUT, 5/16-18 HEX NYLOCK SS
3 86249050 82058 1 PIN, CLEVIS 3/8 X 3.50 PLTD
4 86008670 80606 1 COTTER, 3/8” RING
5 86007020 70673 2 SCR, 5/16-18 X 1.25 HHCS SS
6 86228840 09124 2 BEARING, FLANGED .314 ID X .502 OD
7 86259400 87205 2 WASHER, THRUST .51 ID X 10 D BRO
8 86006320 66338 1 PLATE, SQUEEGEE LIFT
9 86259410 87206 2 WASHER, THRUST .51 ID X 1 OD X .063
10 86239670 41386 1 HOOK, SAFTEY CLIP
11 86003220 27921 1 CABLE, SQUEEGEE LIFT 21.4 L
12 86246460 51351 1 LEVER, SQUEEGEE LIFT
13 86005640 57030 1 NUT, 10-32 HEX NYLOCK
14 86136860 70356 1 SHOULDER BOLT, 5/16 OD X 2.0 L
