WHEEL & FRAME
86221970 17” SCRUBBER 01/03/07
5-30
REF PART
NO. PRV
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86003700
34421
1
FRAME, 17 IN SCRUBBER
2
86223770
70875
2
SCR, 5/16-18 X 1.89 HHCS SS C
3
86011020
89202
2
WHEEL, 3” DIA CUSHION RUBBER
4 86216400 140903 2 BUSHING,
SPANNER .435 X 1.19
5
86078910
620029
2
PLATE, CASTER MOUNT
6
86270830
57023
4
NUT, 5/16-18 HEX NYLOCK SS
7
86070600
140692
2
BRKT, SPLASH GUARD
8
86271770
57252
8
NUT, 10-24 HEX NYLOCK SS
9
86002340
18045
2
CASTER, 3.0 SWIVEL
10
86279130
87083
8
WASHER, 5/16 SPLIT LOCK PLTD
11
86006560
70083
8
SCR, 5/16-18 X 1 HHCS SS NP
12
86276770
70726
8
SCR, 10-24 X 5/8 HHMS SS
13
86010650
87018
8
WASHER, #10 X 9/16 OD
14
86253870
730043
2
SKIRT, CASTER SHIELD
15
86082060
62893
1
PLATE, BRUSH CENTER
16
86273740
70010
3
SCR, 1/4-20 X 1.2 HHCS SS
17
86010810
87191
3
WASHER, 1/4” ID X 1.0 OD FLAT SS
18
86259870
89223
2
WHEEL, 1.25 TREAD X 6 DIA
19
86276750
70722
2
SCR, 5/16-18 X 2.5 FHSC SS
20 OPEN
-
-
-
21 OPEN
-
-
-
22
86087880
730035
2
STRAP, SKIRT SIDE
23
86007320
730029
1
SKIRT, 17” SCRUBBER
24
86276620
70699
8
SCR, 10-24 X 1/2 PTHMS SS
