RECOVERY TANK
86221970 17” SCRUBBER 04/27/07 5-16
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86003340 28062 1 DOME, 13 X 11
2 86006600 70114 4 SCR, #10 X 3/4 PPHST TYPE B SS
3 86222860 620100 1 PLATE, VAC INLET COVER
4 86003680 34380 1 FLOAT SHUT-OFF
5A 86225290 75476 1 TANK, RECOVERY DK GRY
ALL EXCEPT
SCHC172, SCH172
5B 86225280 75475 1 TANK, RECOVERY, TEAL SCHC172, SCH172
6 86003010 27759 1 CUFF, HOSE, 1.5 IN BLACK
7 86246070 51352 1 LANYARD, DRAIN HOSE
SCH172, QSC172 –
QTY OF 2
8 86004290 39491 1 HOSE, 1.5 BLK VAC X 45”
9 86004190 39337 1 HOSE, 1.5 BLK VAC X 24”
10 86002390 20063 4 CLAMP, 1.75” WORM GEAR X .312
11 86225690 84204 1 VALVE, 1.0 BALL PVC
12 86240130 39560 1 HOSE, P-TRAP 45 DEG
13 86004010 35274 1 GASKET, DOME EDGE
14 86218100 35361 1 GASKET, VAC INLET
15 86216790 20109 1 CLIP, VAC HOSE COIL
16 86279880 27425 1 CORD, 1/8” X 16”
17 86215060 140967 1 BAFFLE, AIR INTAKE
18 86223820 70926 2 SCR, 10-32 X .748 PPHMS SS C
19 86222280 57307 2 NUT, 10-32 HEX NYLOCK SS C
20 86010650 87018 2 WASHER, #10 X 9/16 OD
