VACUUM
86221970 17” SCRUBBER 01/03/07
5-28
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86003760 35166 1 GASKET, VAC MTR
2A 86005440 53797 1 VAC MOTOR, 24VDC 2ST TD
2B 86135310 140686 - BRUSH SET, 24/36V VAC, WINDSOR SERVICE ONLY
3 86217750 31374 1 ELBOW, VAC MUFFLER 90 DEG
4 86072620 14433 3 BRKT, VAC MOTOR MNT
5 86216000 149988 1 BRKT, MUFFLER 172
6 86222220 54204 1 MUFFLER, VACUUM FOAM 172
7 86215370 140896 1 BLANKET, SOUND REDUCTION
8 86273750 70011 3 SCR, 1/4-20 X 5/8 HHCS SS NP
9 86010630 87013 3 WASHER, 1/4 ID X 5/8 OD SS
