Watlow EM Gateway - Manual (Page 26)

26
Chapter Seven
Specifications
Power supply
• Voltage input 24 V (ac/dc) +10%, -15% 50/60 Hz +/- 5
• Connection through 2-position removable screw style terminal block
• 22 to 12 AWG
• Power consumption 10 VA MAX
• UL Approved, Class 2 power supply required
• Real-time Clock backed by 3v-lithium battery – RAYOVAC BR1225
Environmental
• Operating temperature range:
0 to 60
°C
• Storage temperature range:
-40 to 70
°C
• Operating and storage humidity: 0 to 90% non-condensing
Indication
• Green LED for Ethernet connection
• Green LED for Ethernet activity
• Green LED for EIA-485 or EIA-232 activity
Agency
• CE Approved, see Declaration of Conformity 61326 Industrial Immunity, Class B Emissions
Communications
• MODBUS RTU communications
• Both EIA-485 and EIA-232 supported at 9600 and 19200 baud
• Connection through 5-position removable screw style terminal block
• 22 to 12 AWG
• Ethernet communications
• Ethernet RJ45 Connector
• 10BaseT per IEEE 802.3 Ethernet Standard
• HTTP v1.1
• Modbus TCP
• DHCP, Auto IP, Or Fixed IP Address
• Email Alarm Notification
• Supports Windows browsers
• Microsoft Internet Explorer 4.0 or newer
• Netscape 4.0 or newer
Control Output Signals
Activity L.E.D. for Ethernet communications per IEEE 802.3
Activity L.E.D. for Serial communications.
Enclosure Size
Dimensional Size - L: 3.75 in X W: 1 in X H: 2.5 in, with cutouts for L.E.D.s, RJ45 port and power jack.
User Interface
3 L.E.D.s to indicate operation status; Ethernet link, Ethernet traffic and Modbus traffic.
Ordering Information
Order part number EM00-GATE-0000
