SCRUB
MOTOR

1. Remove

(4)

screws holding motor

shroud.

Squeegee tracking can be controlled

tension of squeegee

springs.

: Position recovery hose

as shown before making adjustments.

2. Remove batteries and squeegee as-

sembly. Lay machine on side.

3. Remove center screw holding drive

plate. Slide drive plate off motor shaft.

Use

wrench to remove wheel

retaining screw.

4. Disconnect motor leads from terminal

block.

5. Remove

(4)

screws holding brush motor

to scrub deck.

Brush Motor

6.

Remove (2) motor thru-bolts and lift off

end bell. Replace brushes when worn
to

inch.

2. Use arbor press to replace bearings as

required. Use grease gun to lubricate
bearings through zerk fitting on wheel

hub and caster axle.

Limited Warranty:

Windsor Industries warrants that the

terms:

Windsor machine covered by this warranty is free from

defects in workmanship and

under the following

SOLUTION STRAINER

An

solution strainer is located

under chassis behind left wheel. Re-
move sediment bowl and screen period-
ically and rinse clean with hot water.

6

On Rotationally Molded Polyethylene Tanks.

On Traverse Drive Motors, Gear Units, AC Induction Polisher Motors, all Metal

Chassis and Metal Frames.

On all other parts which are not specifically referenced herein, plus an extra

year (2 years total) on Rectified DC Polisher Motors and Scrubber Brush Motors.

The warranty period shall commence at the date of FIRST PURCHASE BY THE END USER

FROM AN AUTHORIZED

DISTRIBUTOR and applies to defective parts only, not

to failure caused by abuse or normal wear.

Windsor will, at its option, repair or replace without charge, except for normal transportation

costs, parts that fail under normal use and service when operated and maintained in accord-

ance with the Owners Instruction Manual and the Preventive Maintenance Guide where

applicable. This warranty shall apply to defects in material and workmanship only and

does not apply to: a) transportation damages, b) alterations by unauthorized persons,

c) misuse or abuse (including use of incompatible or corrosive chemicals or overloading of
capacity), d) failure caused by lack of proper maintenance and cleaning,

batteries and

chargers which are warranted by the original manufacturer for one year, and f) normal

wear on items such as belts, brushes, bearings, capacitors, carbon brushes, clutches,

cords, filters, finishes, gaskets, hoses, pulleys, relays, rectifiers, and switches.

The warranty is in lieu of all warranties, expressed or Implied, and releases Windsor from all

other obligations and liabilities. It is applicable only in the U.S.A., Canada, Australia, and
New

Windsor Industries is not responsible for costs of repairs performed by

other than those specifically authorized by Windsor. This warranty does not apply

to damage or

loss

of income due to

of the machine. USE

OF PARTS NOT

APPROVED BY

WILL VOID WARRANTY.

If

a difficulty develops with this machine, contact either the Dealer from whom you

purchased the product or write to:
