3.

Connect the “DC” charger plug to the
connector on the machine.

NOTE A

safety override switch is activated
when the “ D C charge plug is connected.
This prevents all panel circuits on the
machine from accidentally being
switched on during charging cycle.

4.

Connect charger “AC” plug to properly

rounded outlet that has correct voltage

or the charger.

5. The charger suppled by Wlndsor is

totally automatic and shuts off when
the batteries are fully charged.

Refer to the charger manual for

detailed charging information.

6. After charging check electrolyte level

of the batteries. Add distilled water to

the level as shown in diagram.

FROM

BOTTOM

OF TUBE

BATTERY MAINTENANCE

1. Keep tops of batteries clean and dry.

Use a damp cloth with a weak solution

of baking soda or ammonia and water.
Use a clean dry cloth to wipe battery
tops dry after cleaning.

2. If corrosion (white deposits) appears

on the battery terminals and cable
clamps, remove and clean. Use a battery
terminal and connector cleaning tool.

TERMINAL CLEANER

3. Keep the battery electrolyte at

correct level

-

approximately

below bottom of filler tube of each cell.
Distilled water should be added, as
needed,

AFTER charging cycle.

WARNING:

Do not

electrolyte

level to drop below the tops of the plates.

SERVICING THE
COMPACT SCRUBBER

CAUTION:

Before making any adjust-

ments or repairs to the machine.

. .

1. Only qualified maintenance personnel

are

to

perform repairs.

2. Make sure battery charger is discon-

nected.

3. Make sure all switches are “OFF”.

4.

Remove batteries as required or discon-

nect main battery leads from batteries

when making repairs to electrical system.

5. Refer to wiring diagram when replacing

electrical parts or repairing electrical
system.

VACUUM MOTOR

1. Disconnect battery leads and remove

batteries from compartment.

2. Remove

(6)

screws holding

motor/

plate assembly to recovery tank.

3. Disconnect

motor lead from con-

nector and lift out

assembly.

4. Check motor brushes. When worn to

replace both brushes.

PUMP

ASSEMBLY

(On models equipped with auxiliary pump)

1. Remove batteries and squeegee as-

sembly. Lay machine on side.

2.

Disconnect pump motor leads. Re-
move

(4)

screws holding pump to

chassis. Disconnect solution hoses

from pump head and lift out pump.
Refer to pump drawing for replace-

ment parts.

CAUTION:

When replacing

barbs on pump head-DO NOT

TIGHTEN-as this could crack intake
and exhaust ports in pump head.

SQUEEGEE ASSEMBLY

To remove squeegee assembly.

.

1.

Raise squeegee

arm to store position.

2. Remove

hose from squeegee.

3.

Pull retaining pin from locator stud.
Push down and slide squeegee to the
right to disengage right hand stud from

drag arm.

4. When installing or replacing squeegee

blades make sure the

smooth

of the

blade is next to the squeegee casting.

5. The an

of the squeegee can be

the adjusting screw. Turn

screw clockwise to

squeegee for-

ward and counterclockwise to tilt rear-
ward. Tighten lock nut after making
adjustment.

6. Down pressure can be increased or

decreased with the adjusting nut.

5
