86290230 - pg5-12, Pump – Windsor COMPASS CMPSR 10070080 User Manual
Page 35
PUMP
CMPS 86290230 04/20/07
5-12
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86223390
67488
1
RECTIFIER, 50A 600V BRIDGE
2
86180220
11-800276
1
ELL, 3/8 BR
3
86290290
-
1
UNLOADER, PMPTC EVK-520-450
4
86197510
40010
1
HOSEBARB, 3/8MPT X 3/8 BR DL
5 86197540 40013 1 HOSEBARB,
3/8MPT X 1/2 DL
NOT SHOWN
6
86282270
39631
1
HOSE, 1/2ID WIRE BOUND X 25”
7
86233150
20042
4
CLAMP, 3/8 HOSE (D-SLOT)
8
86256090
730262
1
STRAINER, 1/2 FPT 80 MESH
9
86001530
40039
2
HOSEBARB, 1/2MPT X 1/2 HOSE 90
10
86281980
39549
1
HOSE, 1/2ID WIRE BOUND X 5”
11
86281390
39356
1
HOSE, 3/8ID WIRE BOUND X 12”
12
86290280
-
1
PUMP, PUMPTEC, 500PSI
13
86233090
20016
2
CLAMP, 1/4 ID HOSE
14
86281060
39265
1
HOSE, 1/4ID NYLOBRD X 8”
15
86177610
11-800090
1
CONN, 3/8FP X 1/4P BR
16
86290310
-
1
INJECTOR, TEE 3/8M X 3/8M 1/4 BR
17
86290300
-
1
HOSE, PULSE 48” 3/8MPT X 3/8FPT
18
86190520
11-800224
4
PLUG, 3/8 SOCHD BR
19
86290270
-
1
MOTOR, 120V CIM-PUMPTEC
