Windsor COMPASS CMPSR 10070080 - Manual (Page 31)

VACUUM
CMPS 86290230 02/22/07
5-8
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86237850 35268 2 GASKET, 5.0 OD X 1.75 ID X .38T
2 86092220 270010 1 COVER, VAC MOTOR
3 86238020 36234 1 GASKET, 5.0 OD X 3.1 ID X .75
4 86002390 20063 1 CLAMP, 1.75” WORM GEAR X .312
5 86282120 39582 1 HOSE, VAC EXHAUST X 9”
6 86093590 620004 1 PLATE, VAC MOUNT
7 86004190 39337 1 HOSE, 1.5 BLK VAC X 24”
8 86276940 70758 3 SCR, 1/4-20 X 3.5 HHCS SS NP
9 86201970 065-92 3 VAC SPACER, 2-1/4 II STAGE
10 86003760 35166 1 GASKET, VAC MOTOR
11 86202040 360-04A 1 VAC MOTOR, 120V 5.7 2 ST TD
- 86202070 360-04B - BRUSHES, VAC FOR 116392-00
- 86135320 140687 - BRUSH SET, 120V VAC WINDSOR
- 86028720 53266 - VAC MOTOR ASM, 115V W/ TERM
12 86010630 87013 3 WASHER, 1/4 ID X 5/8 OD SS
13 86005810 57245 3 NUT, 1/4-20 HEX NYLOCK SS
14 86010640 87016 2 WASHER, #10 LOCK EXT STAR SS
15 86274370 70191 1 SCR, 10-24 X 1/2 HHTC TYPE 23
16 86264930 27050 1 CABLE TIE, 3.5” UL/CSA
17 86002380 20046 1 CLAMP, 2.25” WORM GEAR
18 86266130 76044L 2 TERM, 14G MALE COUPLER F/I
19 86010670 87029 5 WASHER, 5/16 FLAT SS
20 86277040 70781 5 SCR, 5/16-18 X 1/2 HHCS SS NP
21 86237870 35270 1 GASKET, 5.0OD X 2.0ID X .50T
22 86078870 620018 1 PLATE, COVER VAC MOUNT
23 86004370 39547 1 HOSE ASM, 1.5 BLK VAC X 21
24 86233260 20092 1 CLAMP, 3.5” WORM GEAR
25 86240240 39697 1 HOSE, 3.15ID X 7.0L VENT
26 86269400 88951 1 WIRE, 10” GRN/18 76008 X 76008
27 86005700 57104 2 NUT, 10-32 W/ STAR WASHER PLTD
28 86006590 70088 1 SCR, 10-32 X 1/2 PPHMS SS NP
