CONTROLS
CMPS 86290230 02/22/07
5-2
REF PART NO.
PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86243990
500780
1
LABEL, COVER PANEL
2
86234690
270012
1
COVER, SWITCH PANEL
3
86270990
57090
2
NUT, 10-32 HEX NYLOCK SS
4
86258930
84187
1
VALVE, CHEMICAL METERING
5
86197390
31021
1
ELBOW, 1/4 NPT 45º STREET
6
86279560
87178
3
WASHER, 5/8 ID X 1.7 OD 0.05 T
7
86230210
14832
1
BREAKER, 6A VDE CIRCUIT
8
86001940
14635
1
BREAKER, 10A CIRCUIT
9
86002450
22015
1
COUPLER, 1/4 QD
10
86002010
14942
2
BOOT, 3/8 CIRCUIT BREAKER
11A
86007130
72128
2
SWITCH, DPDT 2-POSITION POCKER
11B
86007140
72130
1
SWITCH, SPST 2-POSITION ROCKER
12
86290050
-
1
LABEL, SWITCH PANEL, CMPS
13 86078140 61415 1 PANEL,
SWITCH
CONTROL
14
86276600
70696
4
SCR, #10 X 3/4 PTHSMS SS
15
86282280
39634
2
HOSE, 1/4 NYLOBRAID X 23”
16
86232110
270699
2
CAP, CHEM FEED W/DIP TUBE
17
86270800
57104
2
NUT, 10-32 W/ STAR WASHER PLTD
18
86010640
87016
1
WASHER, #10 LOCK EXT STAR SS
19
86238030
36235
2
GASKET, SWITCH CARLING
20
86233090
20016
2
CLAMP, 1/4 ID HOSE
