10. Press a 2Ó Square Inner Cap (56) into each end of the
Leg Press Arm (9).
11. Locate and open the parts bag labeled ÒARM
ASSEMBLY.Ó
Attach the Leg Press Bumper (53) to the Front Seat
Frame (8) with the 1Ó Tap Screw (72).
Lubricate the 3/8Ó x 3Ó Bolt (94). Attach the Leg Press
Arm (9) to the Press Base (13) with the Bolt and a
3/8Ó Nylon Jamnut (43). Do not overtighten the
Nylon Jamnut, it should be easy to pivot the Leg
Press Arm.
12. Press a 1Ó x 7/8Ó Plastic Bushing (54) onto each
welded spacer on the Press Frame (12). Slide the
Press Frame onto the Press Base (13) so that the
Plastic Bushings are aligned with the indicated tube.
Note: This will be a tight fit. Make sure the Press
Frame is oriented with the upper set of holes on
the side shown.
Lubricate the 3/8Ó x 8Ó Bolt (52). Attach the Press
Frame (12) to the Press Base (13) with the Bolt and a
3/8Ó Nylon Locknut (42).
12
10
11
9
9
56
43
94ÑLubricate
53
72
13
54
42
12
13
9
8
56
A
56
56
52ÑLubricate
Tube
Welded
Spacers
Upper
Holes
Arm Assembly
