Weider WESY41080 - Manual (Page 27)

27
Weight StackÑ5
High PulleyÑ1
2
2
3
3
1ÑTop Frame
4ÑWeight Stack
4
WEIGHT PRESS BUTTERFLY LEG HIGH LOW LEG
ARM ARM LEVER PULLEY PULLEY PRESS
PLATES (lbs.) (lbs.) (lbs.) (lbs.) (lbs.) (lbs.)
Top 27 20 9 10 10 52
1 53 37 18 24 24 94
2 79 50 33 40 41 141
3 101 65 38 53 53 180
4 125 83 48 66 63 228
5 148 103 58 80 80 263
6 175 120 68 96 91 310
7 205 143 76 107 101 358
8 240 173 90 123 120 410
This chart shows the approximate weight resistance at each station. ÒTopÓ refers to the 6.5 lbs. top
weight. The other numbers refer to the 12.5 lbs. weight plates. Note: The actual resistance at each
weight station may vary due to differences in individual weight plates, as well as friction between the
cables, pulleys, and weight guides.
Weight Resistance Chart
High Cable (85)
Rear Cable
(87)
