46. Remove the indicated 3/8Ó x 2Ó Bolt (50), the 3/8Ó
Nylon Locknut (42), the 3 1/2Ó Pulley (82) and the
Cable Trap (80) from the indicated Pulley Plates (31).
Lay the Low Cable (86) over the Pulley. Re-attach the
Pulley and the Cable Trap to the lowest hole in the
Pulley Plates with the Bolt and the Nylon Locknut.
Make sure the Cable Trap is turned to hold the
Cable in place.
47. Wrap the Low Cable (86) around a 3 1/2Ó Pulley (82).
Attach the Pulley to the Lat Upright (1) with the 3/8Ó x
3 1/2Ó Bolt (66), a 3/8Ó Washer (38) and a 3/8Ó Nylon
Jamnut (43). The ball on the Cable must be on the
indicated side of the Pulley. Make sure the Cable
and Pulley move smoothly and that the Cable is
between the Pulley and the post.
