Weil-McLain GOLD CGI-4E - Manual (Page 61)

Part Number 550-110-711/1108
61
GOLD CGi-4E Gas-Fired Water Boiler — Boiler Manual
Replacement parts — base
(continued)
12c
Item Description
Weil-McLain
part number
Base assembly kit
(includes base panels items 1, 2, 3, 4, 5, 6
and 7)
CGi-4E 381-354-338
1 Base side panel (in Base assembly)
2
Base front cross-tie assembly (in Base assembly)
3 Base back cross-tie assembly (in Base assembly)
4 Burner shield (in Base assembly)
5
Base pan angle, left side (in Base assembly)
6 Base pan angle, right side (in Base assembly)
7 Base pan (in Base assembly)
7a Base pan air baffle (in Base assembly)
8a Burner mounting plate CGi-4E 450-003-691
8b Rear spacing strip CGi-4E 550-320-161
8c Nut, hex 5mm Zp 550-320-170
9 Base insulation kit CGi-4E 381-354-331
10 Boiler leg kit 550-320-219
11 Manifold CGi-4E 591-126-736
12 Main burner orifice — Natural gas, sea level (see Table 2, page 12 for
orifice size) CGi-4E
Main burner orifice — Propane gas, sea level (see Table 2, page 12 for
orifice size) CGi-4E
560-529-126
560-529-111
13 Burner 512-200-076
14 Screw, 10-32 x . 0.38 STP type 23 hx, washer Hd slot 562-135-710
15 Rollout thermal fuse element 512-050-230
