Firmware Update
71
12. Select Process ISP.
13. Then select Yes.
14. Check the box: Include ISP File
15. Press the Hot Sync button on the cradle or the
cable to sync the computer with the PDA.
16. Click on OK after the ISP File is downloaded
Installing Firmware On a Machine
1. Unlock, open and remove the metercase access
door. Push and hold the service switch until the
process is complete.
2. On a full console machine or on a stack dryer the
service switch is located on the control board near
the P11 Aux connection.
3. Either service switch circuit must remain closed
throughout the update process. Reprogramming
can take up to 4-min. per machine and is only
complete when the word “
done” appears in the
machine’s display.
