MOTOR
86309580 FLOOR POLISHER 10/08/08 5-12
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1A 86312270 - 1 MOTOR, 1HP 115V INDUCTION
SP13, SP15,
SP17, U17,
SPT17, SP20,
U20
1B 86312280 - 1 MOTOR, 1.5HP 115V INDUCTION
SP17X, U17X,
SPT20X,
SP20X, U20X
1C 86312300 - 1 MOTOR, 1HP 230V INDUCTION
SP17IA,
SP17IE
1D 86312310 - 1 MOTOR, 1.5 HP 230V INDUCTION
SP17HDIE,
SP17XIA,
SP17XIE
2 86217490 27884 1 COVER, MOTOR
SP13, SP15,
SP17, U17,
SPT17, SP20,
U20, SP17X,
U17X, SPT20X,
SP20X, U20X,
SP17IA,
SP17IE,
SP17HDIE,
SP17XIA,
SP17XIE
3 86223690 70702 3 SCR, M5 X .8 X 15MM BLK
4 86136710 70698 4 SCR, 5/16-18 X 3/4 HHCS GR5 BLK
5 86279090 87067 4 WASHER, 5/16 LOCK INT STAR PLT
6 86223700 70723 6 SCR, M5 X .8 X 15MM SHCS BLK
7 86223030 62917 1 PLATE, ADAPTER POLISHER MOTOR
8A 86312290 - 1 MOTOR, 115V, 1.75HP 175/300RPM
SPDS20,
UDS20
8B 86312320 - 1 MOTOR, 230V, 1.75HP 175/300RPM
SPDS17IA,
SPDS17IE
9 86217500 27892 1 COVER ASM, MOTOR
SPDS20,
UDS20,
SPDS17IA,
SPDS17IE,
SP17IA,
SP17IE
