Windsor Floor Polisher SP17IE-10090270 - Manual (Page 25)

DECK
86309580 FLOOR POLISHER 10/08/08 5-8
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86214930 03111 1 AXLE, MAIN POLISHER
2A 86216350 14373 1 BUMPER, EXTRUSION 53.4 IN. SP13
2B 86216330 14371 - BUMPER, EXTRUSION 37.3” SP15
2C 86216340 14372 - BUMPER, EXTRUSION 43.8"
U17, U17X, SPT17,
SP17, SP17X,
SP17HDIE, SP17IA,
SP17IE, SP17XIA,
SP17XIE, SPDS17IA,
SPDS17IE
2D 86216350 14373 - BUMPER, EXTRUSION 53.4"
U20,U20X, UDS20,
SPT20X,SP20,SP20X,
SPDS20
3 86216600 27871 2 CAP, EXTRUSION
4 86221860 51328 2 LINK, HANDLE ADJUST
5 86271550 57220 2 NUT, M6 X 1 NYLOCK
6 86222270 57276 2 NUT, PUSH FLAT RD .51 ID
7 86133340 70262 2 SCR, M8-1.25 X 20 HHMS PLTD
8 86276570 70691 2 SCR, M6 X 25 HHCS
9A 86288430 29211 1 DECK, 13 IN POLISHER, BLUE SP13
9B 86288440 29212 1 DECK, 15 IN POLISHER, BLUE SP15
9C 86217600 29213 1 DECK, 17 IN POLISHER, BLUE
SPT17, SP17, SP17X,
SP17HDIE, SP17IA,
SP17IE, SP17XIA,
SP17XIE, SPDS17IA,
SPDS17IE
9D 86288960 29213GRY 1 DECK, 17 IN POLISHER, GRAY U17,U17X
9E 86217620 29214BLU 1 DECK, 20 IN POLISHER BLUE SPT20X,SP20,SP20X,
9F 86288970 29214GRY 1 DECK, 20 IN POLISHER, GRAY U20,U20X, UDS20
10 86288740 70709 1 SET SCR, 8MMX1.25X8MM CUP PT
11 86137280 87054 2 WASHER, M8 FLAT DIN125A PLT
12 86226020 89206 2 WHEEL, 5D X 1.25 X 13MMID GRY
13 86225720 87203 2 WASHER, 14MMID X 36MMOD
14 86137340 87211 2 WASHER, M6 FLAT BLK
