HANDLE
86309580 FLOOR POLISHER 10/08/08 5-10
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86215130 14344 1 BAR, HANDLE ADJUST
2 86216370 14434 1 BUMPER, BURNISHER HANDLE
3 86004070 36196 2 GRIP, POLISHER HANDLE
4 86218440 38290 1 HANDLE, POLISHER
5 86005150 51326 1 LOCK, SAFETY HANDLE
6 86005160 51327 2 LEVER, SWITCH
7 86136350 57274 4 NUT, M6 HEX FINISH
8 86136360 57275 2 NUT, M10 X 1.5 HEX NYLOK PLTD
9 86222560 66334 1 PIN, PIVOT, HANDLE ADJUST
10 86223550 67430 1 ROD, HANDLE ADJUST
11 86274230 70135 2 SCR, M8 X 30 HHMS
12 86136670 70686 2 SCR, M6 X 45 SHCS, BLK
13 86136680 70687 2 SCR, M6 X 50 SHCS, BLK
14 86288450 70689 3 SCR, M4.8 X 10 HHTF TYPE B
15 86136720 70701 1 SCR, M10 X 1.50 X 90 HHCS PLTD
16 86224740 73990 2 SPRING, EXT, .50D X 3.5L
17 86225370 78437 1 TUBE, GRIP HANDLE
18 86137280 87054 2 WASHER, M8 FLAT DIN15A PLT
19 86279080 87058 2 WASHER, M4 FLAT DIN125A PLT
20 86010720 87086 3 WASHER, M10 X 30 PLTD
21 86225710 87202 1 WASHER, BEARING (HANDLE ADJ)
22 86137330 87208 1 WASHER, M5 LOCK SHAKEPROOF PLTD
23 86224290 730008 2 SPACER, .317ID X .5OD X .44LG
24 86310950 - 1 CLAMP, HANDLE
25 86311800 - 1 TUBE ASSY, HANDLE ADJ.
26 86311810 - 1 HOUSING, POLSHR HANDLE RR, CB
27 86311820 - 1 HOUSING, POLSHR HANDLE FRT,CB
