Windsor Floor Polisher SP17IE-10090270 - Manual (Page 23)

ELECTRICAL-230V
86309580 FLOOR POLISHER 10/08/08 5-6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86002010 14942 1 BOOT, 3/8 CIRCUIT BREAKER
2 86198450 20005 1 CLAMP, 5/16 NYLON
3A 86216950 23212
CORD SET, EURO 1.5MM X 75
BLK
SP17HDIE,
SP17IE, SPX17IE,
SPDS17IE
3B 86216970 23217 CORD SET, SAA33 1.5MM X 75
SP17IA, SP17XIA,
SPDS17IA
4 86216920 23206 1 CORDSET, 14/3 X 52 IN, SJT, BLK
5 86268450 70689 1 SCR, M4.8 X 10 HHTF TYPE B
6 86136780 70801 2 SCR, M3.5 X 40 PHTF
7 86007110 72123 2 SWITCH, 25A SPST 125-250V
8 86224750 73993 1 SPRING, COMP, .48OD X .91
9 86137290 87057 2 WASHER, M4 LOCK
10 86137330 87208 1 WASHER, M5 LOCK
11 86215140 140674 1 BARRIER SHEET
12 86224930 730012 1 STRAIN RELIEF, 14/3 STRAIGHT
13 86224300 730021 1 SPACER, POLISHER HANDLE
14A 86312470 - 1 BREAKER, 3A, VDE CIRCUIT SP17IA, SP17IE
14B 86215710 141046 1 BREAKER, 5A VDE CIRCUIT
SP17HDIE,
SP17XIA, SP17XIE
14C 86312530 - 1 BREAKER, CIRCUIT 10A, VDE
SPDS17IA,
SPDS17IE
