4-Port Router (Model 2400) User Guide
Table 2. Connector Descriptions
C ONNECTOR N AME T YPE F UNCTION
DSL 6-pin RJ-11 modular jack
Connects to an ADSL-equipped telephone jack or
DSL connection of a POTS splitter.
Power Barrel connector Power source.
USB 4-pin USB Series B connector Connects the USB device to the PC.
Ethernet 8-pin (RJ-45) modular jacks Connects four PCs or peripherals together.
Table 3. DSL Pinouts
Pinout Description
1, 2, 5, 6 Not Used
3 DSL Tip
4 DSL Ring
Table 4. USB Series B Connector Pinouts
Pin Name Description Cable Color
1 VBUS/Vcc 5 Vdc Red
2 D – Data – White
3 D + Data + Green
4 GND Ground Black
Table 5. Ethernet Pinouts
Pinout Description
1 Rx+
2 Rx-
3 Tx+
4,5,7,8 Not Used
6 Tx-
