Westell Technologies Router 2400 - Manual (Page 80)

030-300331 Rev. A 78 October 2002
4-Port Router (Model 2400) User Guide
9.5 Maintenance
Backup/Store
The following settings will be displayed if you select Backup/Restore from the Maintenance menu.
Current configuration
becomes Backup
Configuration Select this button if you want to store all of the current configuration data
such that it can be recalled later.
Backed up configuration
becomes Current
configuration Select this button if you want to retrieve the last back up copy of all
configuration parameters and make these values current.
Factory default becomes
Current configuration Select this button if you want set all user configurable parameters back to the
factory default.
Firewall Log
The following settings will be displayed if you select Firewall Log from the Maintenance menu.
This screen is an advanced diagnostics screen. It alerts you of noteworthy information sent to your Router from the
Internet. The screen can contain 1000 entries, but a maximum of 50 entries are displayed at a time. Once 1000
entries have been logged, the oldest entry is removed to make space for the new entries as they occur. The following
settings are displayed.
