Port Forwarding Ranges of Ports
If you select Port Forwarding Ranges of Ports from the Custom Service screen, the following settings from the
Port Range screen will be displayed. Click on next to continue.
Service Name
The NAT service you selected.
Local IP Address
If a static IP address has been assigned, it will be displayed here.
Global Port Range
The port range that is provided by the service that you are customizing.
Protocol
The type of Protocol that is used to run this NAT service.
The screen below displays a message that the NAT service has been added. Click on done.
