Titan TM Series
24
SPECIFICATIONS - Titan™ ACTIVE (Con't)
Inputs
Input A – type
Input Sensitivity
Maximum Input Level
Input Connector
Input Impedance
Maximum Input Level
Input B – type
Input Sensitivity
Maximum Input Level
Input Connectors
Line Output
Line Output Connector
Impedance:
Sensitivity
AC Power details
Power Supply
AC Power Options
Power On Indicator
Rigging / Bracket / Mounting
Options
Enclosure Material
Colours
Dimensions H x W x D (mm)
Dimensions H x W x D (in)
Net Weight (kg / lbs)
Gross Weight (kg / lbs)
Titan™ 8 ACTIVE
Switchable balanced mic or line
level input
Mic: -36dBu (-38.2dBv or
12.28mVrms)
Line: +4dBu (1.78dBv or 1.228Vrms)
+22dBu
XLR - 1/4” Combo jack
Balanced: 20k ohms
+22dBu
High Efficiency Switching Mode
Power Supply
AC100~120V / 220~240V, 50 /
60Hz
LED
8 M6 threaded inserts including 4
M6 threaded
inserts on bottom in OmniMount
30.0-type footprint
Pole-mount receptacle with lock
screw
1 carry handles ( on each side)
Optional wall-mount bracket
Injection Moulded Polypropylene
Grey or white or black
396 x 266 x 221
15.6 x 10.5 x 8.7
5.7kg / 12.54lbs
7.70kg /16.94lbs
Titan™ 12 ACTIVE
Switchable balanced mic or line
level input
Mic: -36dBu (-38.2dBv or
12.28mVrms)
Line: +4dBu (1.78dBv or
1.228Vrms)
+22dBu
XLR - 1/4” Combo jack
Balanced: 20k ohms Unbalanced:
10k ohms
+22dBu
Line level input
XLR - 1/4” Combo jack: 1.78dBv
or 1.228Vrms
RCA: 0dBu (-2.2dBv or
0.775Vrms)
+22dBu
Combo jack: 1/4" - XLR / Summed
dual RCA jacks
Switchable LOOP / MIX Balanced
Male XLR
Balanced: 1k ohm Unbalanced:
500 ohm
+4dBu (1.78dBv or 1.228Vrms)
High Efficiency Switching Mode
Power Supply
AC100~120V / 220~240V, 50 /
60Hz
LED
10 M8 threaded inserts including
4 M8 threaded
inserts on bottom in OmniMount
60.0-type footprint
Pole-mount receptacle with lock
screw
2 carry handles (one on each
side)
Optional wall-mount bracket
Injection Moulded Polypropylene
Grey or white or black
556 x 384 x 312
21.9 x 15.1 x 12.3
12.8kg / 28.16lbs
14.8kg / 32.56lbs
Titan™ 15 ACTIVE
Switchable balanced mic or line
level input
Mic: -36dBu (-38.2dBv or
12.28mVrms)
Line: +4dBu (1.78dBv or
1.228Vrms)
+22dBu
XLR - 1/4” Combo jack
Balanced: 20k ohms Unbalanced:
10k ohms
+22dBu
Line level input
XLR - 1/4” Combo jack: 1.78dBv
or 1.228Vrms
RCA: 0dBu (-2.2dBv or
0.775Vrms)
+22dBu
Combo jack: 1/4" - XLR /
Summed dual RCA jacks
Switchable LOOP / MIX Balanced
Male XLR
Balanced: 1k ohm Unbalanced:
500 ohm
+4dBu (1.78dBv or 1.228Vrms)
High Efficiency Switching Mode
Power Supply
AC100~120V / 220~240V, 50 /
60Hz
LED
10 M8 threaded inserts including
4 M8 threaded
inserts on bottom in OmniMount
60.0-type footprint
Pole-mount receptacle with lock
screw
2 carry handles (one on each
side)
Optional wall-mount bracket
Injection Moulded Polypropylene
Grey or white or black
708.3 x 477.8 x 401.8
27.9" x 18.8" x 15.8
23.94kg / 52.67lbs
26.94kg / 59.27lbs
