Wharfedale Programme 1LT - Manual

Unpacking
All Wharfedale Systems products are fully
checked before leaving the factory. After
unpacking please inspect cabinets for any
physical damage. Please retain the shipping
carton if possible and internal packing material in case the unit needs
to be returned. Please check as soon as possible the unit is
functioning. In the event of any damage please contact your dealer
immediately so that a written claim for damages can be made.
Wharfedale Systems Limited Warranty*
In the event of malfunction, contact your authorised Wharfedale
Professional dealer or distributor for information.
*Be aware that warranty details may differ from country to country. Contact your dealer or
distributor for information.
These terms do not infringe your statutory rights.
Operating/Use
1. The Programme 1 &1LT accept stripped bare end cables. The
Programme 1 has a push and clip connector at the rear of each
cabinet. The 1LT features a barrier strip.
2. Attach the speaker cable securely to your Programme Series unit
and power amplifier (the amplifier should be off, power down
mode). Try to use the correct type of speaker cable according to the
handling ability of your Programme Series Cabinet. Use 2 core equal
stranded insulated cable for speaker runs. It is always advisable to
use heavier conductor cables on longer runs.
3. Power up amplifier with levels on zero. Confirm units are operating.
● Proprietary designed, high efficiency, high power
Wharfedale Professional drive units
● Sophisticated crossover design enables smooth
power and frequency response control through
crossover region.
● Integral High Frequency Driver Overload protection
“PRO-TECH”™
● 100mm full range drive unit with copper clad
magnet poles
● High power output, low distortion sound quality
● 100 volt ine system with switchable power tapping
on Programme 1LT
● Wall bracket included constructed in powder coated
steel and adjustable on three planes.
● Constructed from Mineral Loaded Polypropylene
● Available in black or cream (finish is paintable)
● Small compact size
ƽ W A R N I N G & S A F E T Y I N S T R U C T I O N S
Programme 1 & 1LT Professional Sound Reinforcement Loudspeakers
1. READ INSTRUCTIONS carefully before operating this product.
2. RETAIN these instructions.
3. COMPLY WITH WARNINGS - All warnings and instructions for
this product should be adhered to.
4. USE WITH AMPLIFIERS - In order to avoid damage, it is
advisable to establish and follow a pattern for turning on and off
any sound system. With all system parts connected, turn on
source equipment, tape decks, instruments, mixers, signal
processors etc., BEFORE turning on your power amplifier. Many
products output turn on and turn off transients that can damage
speakers. By turning on your power amplifier LAST and making
sure the amplifier’s input controls are at minimum any transients
“upstream” of the amplifier are not amplified and passed to the
speaker. Wait until all system parts have stabilised, then bring up
amplifier controls to operating level. This should take no more
than a few seconds. Similarly when shutting systems down,
always turn down amplifier input controls and then turn off your
amplifier BEFORE shutting down other components. Professional
amplifiers often feature delayed turn on/off circuits to perform
these functions for you automatically.
5. CABLES - Never use shielded or microphone cable for any
speaker connection as this will not be heavy enough to handle the
amplifier load and could cause damage to the complete system.
6. ƽ ṑ RIGGING • SUSPENDING • MOUNTING
The rigging, suspension or mounting of this speaker system can
expose members of the public to serious health risks and even
death. UNDER NO CIRCUMSTANCES ATTEMPT TO RIG,
SUSPEND OR OTHERWISE MOUNT THIS SYSTEM UNLESS
YOU ARE FULLY QUALIFIED AND CERTIFIED TO DO SO BY
RELEVANT LOCAL, STATE AND NATIONAL AUTHORITIES.
ALL RELEVANT SAFETY REGULATIONS MUST BE
FOLLOWED. IF YOU ARE NOT PROPERLY QUALIFIED OR DO
NOT KNOW OF PERTINENT REGULATIONS, CONSULT
QUALIFIED PERSONNEL FOR ADVICE AND ASSISTANCE.
7. Ꮧ CAUTION: These professional loudspeaker systems are
capable of generating very high sound pressure levels. Use care
with placement and operation to avoid exposure to excessive
levels that can cause permanent hearing damage.
8. SERVICING - The user should not attempt to service this
product except that mentioned in this manual.
P R O G R A M M E 1 & 1 L T L O U D S P E A K E R
PROGRAMME SERIES LOUDSPEAKERS
USER MANUAL
PROGRAMME 1, 1LT
WHARFEDALE SYSTEMS DIVISION
