Titan TM Series
22
SPECIFICATIONS - Titan™ PASSIVE SERIES
Loudspeaker Type:
Frequency Response (+/–3dB):
Sensitivity (1W@1M):
Peak SPL:
HF Coverage (H x V):
System Impedance:
POWER (WATTS)
Continuous:
Music:
Peak:
LF DRIVER
Size:
Coil Size:
HF DRIVER/ HORN
Coil Size:
Exit Size:
Diaphragm Material:
HF Driver Protection:
Long-Throw EQ Compensation:
Horn Type:
Throat Size:
CROSSOVER
Type/Frequency/Filter:
ENCLOSURE
Shape/ Material:
Rigging:
COLOURS
OUTPUT CONNECTORS
DIMENSIONS/WEIGHTS
Weight:
Dimensions (H x W x D):
Titan™ 8
8" 2-way
70 - 20kHz
96dB
124dB
Э[Э
8 ohm
150W
300W
600W
203mm/ 8"
38.86mm / 1.53"
Compression Driver
25mm/1"
30mm/1.2"
Cloth
Bulb
N/A
EWG™ - Elliptical Waveguide
25mm/1"
2-way 2.4KHz / Linkwitz-Riley
Trapezoidal/ Polypropylene
(8) M6 threaded rigging points
+ (4) M6 threaded rigging points
on bottom in Omnimount®
30.0-type footprint + Speaker pole-
mount receptacle with lock screw
+ 1 built-in carry handle + Optional
wall-mount bracket + Optional
dual-unit array speaker stand
hardware
Grey or Black or White
2 x 1/4" jacks + 2 x NL4
5.5kg / 12.1lbs
396 x 266 x 221mm/
15.59" x 10.47" x 8.7"
Titan™ 12
12" 2-way
55 - 20kHz
98dB
128dB
Э[Э
8 ohm
250W
500
1000
305mm/ 12"
64.26mm / 2.5"
Compression Driver
44mm/1.75"
25mm/1"
Titanium
DTF™ Dynamic Thermal Filament
3dB boost (long-throw) / Flat
(near-field)
EWG™ - Elliptical Waveguide
25mm/1"
2-way 2.2KHz / Linkwitz-Riley
Trapezoidal/ Polypropylene
(10) M8 threaded rigging points
+ (4) M8 threaded rigging points
on bottom in Omnimount®
60.0-type footprint + Speaker
pole-mount receptacle with lock
screw + Optional wall-mount
bracket + Optional dual-unit
array speaker stand hardware
Grey or Black or White
2 x 1/4" jacks + 2 x NL4
12kg / 26.4lbs
556 x 384 x 312mm/
21.88" x 15.1" x 12.3"
Titan™ 15
15" 2-way
50 - 20kHz
97dB
129dB
Э[Э
8 ohm
400W
800W
1600W
381mm/ 15"
75mm / 3.0"
Compression Driver
51mm/ 2.0"
25mm/1"
Titanium
DTF™ Dynamic Thermal Filament
N/A
25mm/1"
2-way 1.8KHz / Linkwitz-Riley
Trapezoidal/ Polypropylene
(10) M8 threaded rigging points
+ (4) M8 threaded rigging points
on bottom in Omnimount®
60.0-type footprint + Speaker
pole-mount receptacle with lock
screw + Optional wall-mount
bracket + Optional dual unit
array speaker stand hardware
Grey or Black or White
2 x 1/4" jacks + 2 x NL4
22kg / 48.4lbs
708.3 x 477.8 x 401.77mm/
27.9" x 18.8" x 15.8
