Windsor Saber Compact 16 - Manual (Page 13)

English
13
You will find a list of spare parts at the end of
these operating instructions.
Specifications
Power
Nominal voltage V/Hz 120 / 1~60
Average power consumption W 2750
Suction motor output W 650
Brush motor output W 2100
Vacuum
Vacuum power, air volume gpm / l/s 634 / 40
Vacuum power, negative pressure psi / kPa 21.7 / 150
Cleaning brush
Working width in / mm 15.4 / 390
Brush diameter in / mm 15.2 / 385
Brush speed 1/min 90
Dimensions and weights
Approximate surface cleaning performance ft²/h / m²/h 17200 / 1600
Capacity of fresh/dirty water tank gal / l 6.6 / 25
Length (without push handle) in / mm 34.3 / 870
Width (without squeegee tool) in / mm 22.6 / 575
Height (without push handle) in / mm 32.7 / 830
Weight (with tank empty) lbs / kg 143 / 65
Noise emission
Medium sound power level according to EN 60704 dB(A) 70
Vibrations in machine
Total vibration value (ISO 5349) m/s² 1,0
Spare parts
