26
Vidikron Vision Model 10/Model 12 Owner’s Operating Manual
PRE
L
IMINAR
Y
Component Video Connections: If you have a DVD player or DTV decoder with a
component (YPbPr) output, connect it to the Vision 10/12 as shown in Figure 3-10.
Figure 3-10. Component Video Connections
Composite/S-Video Connections: The Vision 10/12 has S-Video and composite video
inputs for connecting a VCR, camcorder, laser disc player or DVD player; see Figure 3-11.
Figure 3-11. Composite and S-Video Connections
DVD player or
DTV decoder
Component cable
Video equipment
Video cable
S-Video cable
