Vidikron Vision Model 10/Model 12 Owner’s Operating Manual
19
PRE
L
IMINAR
Y
Figure 3-5. Horizontal Lens Shift
0%
Screen Center
100% Width Lens Shift
(1.0 x W)
50% Width Lens Shift
(0.5 x W)
150% Width Lens Shift
(1.5 x W)
Screen Width (W)
Note:
This is a general example of lens shift. Lenses vary in their shift capabilities. No particular lens is used
in this example.
